Grit SX - Titanium Gravel Frameset

Frameset parts

Grit SX - Titanium Gravel Frameset

Our goal in designing the Grit SX was to create a gravel bike that is ‘more’ in every area. Better handling, more clearance, easier service, more versatility, more fun. The Grit SX is a complete overhaul of its predecessor with a raft of new features and reworked geometry. We have loaded the SX with everything that we'd want from a gravel/adventure bike in a package that is both tighter and more focused than the original Grit. Is it more road or off-road? The answer is ‘both’.

The front end has been completely reworked. At the heart of those changes is the fork’s new ‘flip chip’, allowing riders to choose between road and off-road handling. In the 52mm setting, trail is reduced which quickens the handling creating a more responsive ride for the road. Flipping to the 47mm setting increases the trail resulting in more stability and wheel flop helping riders navigate tight and technical terrain. Shorter chainstays mean more direct drive and a shorter wheelbase which keeps the package feeling tight and responsive. The headtube has been lowered for a slightly more aggressive stance, balancing more weight on the bars for more feel and control. Tyre clearance is now up to a whopping 700x50c (2.2” 650b) and chainring clearance up to 1x46T. This increased clearance, and shorter chain stays, are made possible by our new fully internal routed 6-axis CNC yoke. This yoke is the cornerstone of the rear triangle redesign, an elegant solution to a complex problem where multiple components are competing for limited space.

The SX now features our fully internal routed T47 bottom bracket. T47 combines the efficiency of larger bearings with maintenance friendly threads and compatibility with all axle diameters. We’ve added a 3rd bidon mount on the underside of the down tube and an adjustable bidon position on the seat tube to accommodate 1L bottles – a helpful inclusion for any bikepacking excursion. The new fork now features fully recessed rack bolts for a cleaner profile, internal cable routing for dynamo hubs, and clearance for fenders – all the bikepacking bells and whistles. We don’t believe there is ‘one bike to do it all’ but the Grit SX sure comes close. A durable and engaging gravel bike, a spirited and comfortable road bike, a versatile and dependable tourer.

  • 3AL-2.5V titanium TT,DT,CS,SS,ST
  • 6AL-4V titanium bottom bracket (T47 86mm)
  • 6AL-4V titanium headtube
  • 6AL-4V titanium dropouts
  • Butted seatpost and downtube
  • Hydroformed top tube with flattened underside
  • Hydroformed double-ovalised downtube
  • CNC chainstay yoke
  • Braze-on front derailleur
  • Toray T800 monocoque carbon flat-mount disc fork
  • 52/47mm fork offset
  • Internal dynamo cable routing
  • Double ovalised chainstays
  • Tapered and lowered seatstays
  • 3x bidon mounts
  • Clearance for 1L bottles
  • Flat mount disc brakes
  • 12 x 100mm front and 12 x 142mm rear Thru-axle
  • Tapered headtube 1 1/8” – 1 1/2"
  • Integrated headset
  • Di2/ETAP compatible
  • 3D CNC dropout
  • Internal cable routing
  • 27.2mm seatpost
  • Laser engraved logos
  • Pannier rack mounts on fork and seat stays
  • Full fender mounts front and rear
  • Clearance for 50c(700c) and 2.2"(650b) tyres
  • Brush Finish
  • CNC engraved headtube
  • Suitable for 700c and 650b wheelsets



Standard: Each frameset comes as standard with frame, carbon fork, carbon seatpost, headset, expansion nut, alloy spacers, thru axles, and seatpost clamp.

Titanium: If you would like to add some bling to your build, you can upgrade to a titanium seatpost, seatpost clamp, dustcap, top cap, and spacers during checkout by selecting 'Titanium Frameset Parts'.


Australia: Our titanium framesets are available to order online or through any of our authorised dealers. We offer free domestic shipping on all framesets and custom builds. To discuss build options, get in touch with us or speak to your nearest dealer.  Finance is provided through ZIP and can be used for both frameset and custom build purchases.

International: We offer door to door shipping internationally through TNT/FEDEX and DHL. Visit our Shipping page for full breakdown on fees and terms.
